Thread: Snout Seal Replacement

  1. #1
    Join Date
    Apr 2002
    Location
    Lakeville, MN
    Posts
    13,517

    Question Snout Seal Replacement

    My snout seal has started leaking. I had to put a full bottle of GM fluid in to bring it up to the proper level.

    Does this repair require removal of the SC and disassembly of the snout? Most threads i found in searching was for people that already had to replace bearings as well.

    Or can I just pull the front pulley to get access to the seal for replacement?

    Anyone with hints for this job? Thanks

  2. #2
    Yes you can replace just the snout seal or you can buy a rebuilt snout.

  3. #3
    Join Date
    May 2003
    Location
    London Ontario
    Posts
    2,143
    Yes you can replace the seal without removing the blower. The seal is made by Chicago Rawhide part # 7968. The pully can be removed to access the seal. You may need to go a machine supply store or a bearing supply store for the seal. In my experience Ford doesn't carry them anymore.
    Good luck!
    SCCoA Member # 2246


  4. #4
    Join Date
    Apr 2002
    Location
    Lakeville, MN
    Posts
    13,517
    Thanks guys. Locally Gopher Bearing is my main source for odd bearings and seals. So I'll be trying them and see if they have a sane price. Otherwise I saw Tbird88 had some for sale.

  5. #5
    Join Date
    May 2003
    Location
    London Ontario
    Posts
    2,143
    Price should not be too bad. I live in Canada and it was only $16.00 here so it's probrably about $5.00 in the US!!!
    SCCoA Member # 2246


  6. #6
    Join Date
    Apr 2002
    Location
    Medina, OH (outside Cleveland)
    Posts
    2,998

  7. #7
    Join Date
    Apr 2002
    Location
    Lakeville, MN
    Posts
    13,517
    Thanks George. i'll remember some terms for the time I need to search on that again.

  8. #8
    Join Date
    Jun 2002
    Location
    So Cal
    Posts
    79
    I have several kits to repair the snout. All kits come with instructuions and are shipped free to the lower 48. The seal is $10.00 the seal and bearings kit is $30.00. I have a solid coupler for $15.00. I also have the two bearings that go in the rear of the blower housing $10.00 each. Contact me at FLBATFISH@aol.com if I can help U.

  9. #9
    Join Date
    Apr 2002
    Location
    Lakeville, MN
    Posts
    13,517
    Originally posted by KarDoktor
    I have several kits to repair the snout. All kits come with instructuions and are shipped free to the lower 48. The seal is $10.00 the seal and bearings kit is $30.00. I have a solid coupler for $15.00. I also have the two bearings that go in the rear of the blower housing $10.00 each. Contact me at FLBATFISH@aol.com if I can help U.
    Thanks,

    I saw your add but feel that I'll be o.k. with just the seal. My SC isn't making any noises that I'm concerned with. But if I do end up needing a kit, I'll be contacting you.
